KYMCO Super 8 50 Service Manual

15. IGNITION SYSTEM
3
Super 8 50
IGNITION COIL
REMOVAL
Remove the met-in box. (

2-3)
Remove the spark plug cap.
Disconnect the ignition coil wires and remove
the ignition coil bolt and ignition coil.
INSPECTION
CONTINUITY TEST
Measure the resistance between the ignition
coil primary coil terminals.
Resistance: 0.1～1.0
Measure the secondary coil resistances with
and without the spark plug cap.
Resistances:
(with plug cap) : 7～12K
(without plug cap) : 3～5K
Ignition Coil
Correctly operate the tester following the
manufacturer‘s instructions.
＊

KYMCO Super 8 50 Specifications

General

Displacement	49.5 cc
Fuel System	Carburetor
Ignition	CDI
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Front Tire	120/70-12
Rear Tire	130/70-12
Cooling System	Air
Transmission	CVT Automatic
Seat Height	780 mm
Wheelbase	1, 280 mm
