KYMCO Super 8 50 Service Manual

3. INSPECTION/ADJUSTMENT
3-5
SUPER 8 50
VALVE CLEARANCE
Remove the frame cover. (

2-3)
Remove the six bolts on the cylinder head
cover.
Remove the cylinder head cover. (

7-3)
Remove the cylinder head cover..
Turn the flywheel counterclockwise so that
the “T” mark on the flywheel aligns with the
index mark on the crankcase to bring the
round hole on the camshaft gear facing up to
the top dead center on the compression
stroke.
Inspect and adjust the valve clearance.
Valve Clearance: IN : 0.1mm
EX: 0.1mm
Loosen the lock nut and adjust by turning the
adjusting nut
Tappet Adjuster
Inspect and adjust valve clearance while
the engine is cold (below 35℃).
＊
Special
 Check the valve clearance again after
the lock nut is tightened.
＊
Cylinder Head Cover
Bolts
Round Hole
Tappet Adjuster
Feeler Gauge

KYMCO Super 8 50 Specifications

General

Displacement	49.5 cc
Fuel System	Carburetor
Ignition	CDI
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Front Tire	120/70-12
Rear Tire	130/70-12
Cooling System	Air
Transmission	CVT Automatic
Seat Height	780 mm
Wheelbase	1, 280 mm
