3. INSPECTION/ADJUSTMENT
NUTS/BOLTS/FASTENERS
Check all important chassis nuts and bolts for
looseness.
Tighten them to their specified torque values
if any looseness is found. (
1-11)
WHEELS/TIRES
Check the tires for cuts, imbedded nails or
other damages.
Check the tire pressure.
TIRE PRESSURE
TIRE SIZE
Front : 120/70
-
14
Rear : 120
/
80
-
14
Check the front axle nut for looseness.
Check the rear axle nut for looseness.
If the axle nuts are loose, tighten them to the
specified torques.
Torques: Front : 5.0～7.0kgf-m
Rear : 11～13kgf-m
STEERING HANDLEBAR
Check that the control cables do not interfere
with handlebar rotation.
Raise the front wheel off the ground and
check that the steering handlebar rotates
freely.
If the handlebar moves unevenly, binds, or has
vertical movement, adjust the steering head
bearing.
Tire pressure should be checked when
tires are cold.
