10. FINAL REDUCTION
10-4
Super 8 50
BEARING REPLACEMENT
(LEFT CRANKCASE)
Remove the drive shaft.
Remove the drive shaft oil seal.
Remove the left crankcase bearings using a
bearing puller.
Bearing Puller
Drive new bearings into the left crankcase.
Install a new drive shaft oil seal.
FINAL REDUCTION ASSEMBLY
Install the drive shaft into the left crankcase.
Install the final gear and final shaft into the
left crankcase.
Pilot
Drive Shaft
Bearing Puller, 12mm
Outer Driver, 32x35mm
Special

KYMCO Super 8 50 Specifications

General

Displacement	49.5 cc
Fuel System	Carburetor
Ignition	CDI
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Front Tire	120/70-12
Rear Tire	130/70-12
Cooling System	Air
Transmission	CVT Automatic
Seat Height	780 mm
Wheelbase	1, 280 mm
