KYMCO Super 8 50 Service Manual

16. STARTING SYSTEM
16-1
Super 8 50
SERVICE INFORMATION
GENERAL INSTRUCTIONS
 The removal of starter motor can be accomplished with the engine installed.
SPECIFICATIONS
Item
Standard (mm)
Service Limit (mm)
Starter motor brush length
12.5
8.5
TORQUE VALUES
Starter clutch cover socket bolt 1.2kg-m
Starter clutch lock nut 9.5kg-m
SPECIAL TOOLS
Flywheel Holder
TROUBLESHOOTING
Starter motor won‘t turn Lack of power
 Fuse burned out  Weak battery
 Weak battery  Loose wire or connection
 Faulty ignition switch  Foreign matter stuck in starter motor
 Faulty starter clutch
or gear
 Faulty front or rear stop switch
 Faulty starter relay Starter motor rotates but engine does
 Poorly connected, broken or shorted wire
not start
 Faulty starter motor  Faulty starter clutch
 Starter motor rotates reversely
 Weak battery
SERVICE INFORMATION ....................... 16-1 STARTER MOTOR ................................ 16-2
TROUBLESHOOTING .............................. 16-1 STARTER RELAY .................................. 16-4

KYMCO Super 8 50 Specifications

General

Displacement	49.5 cc
Fuel System	Carburetor
Ignition	CDI
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Front Tire	120/70-12
Rear Tire	130/70-12
Cooling System	Air
Transmission	CVT Automatic
Seat Height	780 mm
Wheelbase	1, 280 mm
