5. FUEL INJECTION SYSTEM Super 8 50
5
FUEL INJECTION SYSTEM
SYSTEM DIAGRAM ............................................................................ 5 - 1
SYSTEM LOCATION ........................................................................... 5 - 2
SERVICE INFORMATION .................................................................. 5 - 3
TROUBLESHOOTING ......................................................................... 5 - 4
CHECK ENGINE LAMP (CELP) ......................................................... 5 - 5
HOW TO SHOW THE FAILURE CODE ............................................. 5 - 6
FAILURE CODES CHART .................................................................. 5 - 7
ECU ........................................................................................................ 5-11
FUEL PUMP .......................................................................................... 5-12
T-MAP & TPS........................................................................................ 5-13
WTS ........................................................................................................ 5-14
INJECTOR ............................................................................................. 5-14
O
2
SENSOR ........................................................................................... 5-15
ROLL SENSOR ..................................................................................... 5-16
TP SCREW ............................................................................................. 5-16
TPI / ABV INITIALIZATION .............................................................. 5-17
DIAGNOSTIC REPORT ....................................................................... 5-18
Fi DIAGNOSTIC TOOL OPERATION INSTRUCTIONS .................. 5-19
