4. LUBRICATION SYSTEM
4-1
Super 8 50
SERVICE INFORMATION
GENERAL INSTRUCTIONS
 The maintenance of lubrication system can be performed with the engine installed in the frame.
 Use care when removing and installing the oil pump not to allow dust and foreign matters to enter
the engine and oil line.
 Do not attempt to disassemble the oil pump. The oil pump must be replaced as a set when it
reaches its service limit.
 After the oil pump is installed, check each part for oil leaks.
SPECIFICATIONS
Item
Standard (mm)
Service Limit (mm)
Inner rotor-to-outer rotor clearance

0.12
Oil pump
Outer rotor-to-pump body clearance

0.12
Rotor end-to-pump body clearance
0.05～0.10
0.2
TROUBLESHOOTING
Oil level too low Poor lubrication pressure
 Natural oil consumption  Oil level too low
 Oil leaks  Clogged oil filter or oil passages
 Worn or poorly installed piston rings  Not use the specified oil
 Worn valve guide or seal
