KYMCO Super 8 50 Service Manual

7. CYLINDER HEAD/VALVES
7-3
Super 8 50
CAMSHAFT REMOVAL
Remove the center cover.
Remove the four cylinder head cover bolts
to remove the cylinder head cover.
Remove the two nuts attaching the
secondary air inlet tube.
Remove the cam chain tensioner cap screw
and the O-ring.
Turn the cam chain tensioner screw
clockwise to tighten it.
Turn the flywheel counterclockwise so that
the “T” mark on the flywheel aligns with the
index mark on the crankcase to bring the
round hole on the camshaft gear facing up to
the top dead center on the compression
stroke.
Cylinder Head Cover
O-ring
Tensioner Screw
Round Hole
Camshaft Gear
Screw
Punch Marks

KYMCO Super 8 50 Specifications

General

Displacement	49.5 cc
Fuel System	Carburetor
Ignition	CDI
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Front Tire	120/70-12
Rear Tire	130/70-12
Cooling System	Air
Transmission	CVT Automatic
Seat Height	780 mm
Wheelbase	1, 280 mm
