KYMCO Super 8 50 Service Manual

12. FRONT WHEEL/FRONT BRAKE/
FRONT SUSPENSION
12-8
Super 8 50
Brake Pad/Disk Replacement
Remove the two bolts attaching the brake
caliper.
Remove the brake caliper.
Downpress reed and remove the brake pads.
Install the brake pads in the reverse order of
removal.
Brake Disk
Measure the brake disk thickness.
Service Limit: 3.0mm
Measure the brake disk runout.
Service Limit: 0.3mm
The brake pads must be replaced as a
set to ensure the balance of the brake
disk.
＊
‧Keep grease or oil off the brake pads
to avoid brake failure.
＊
Reed
Front Brake Caliper
Brake pads

KYMCO Super 8 50 Specifications

General

Displacement	49.5 cc
Fuel System	Carburetor
Ignition	CDI
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Front Tire	120/70-12
Rear Tire	130/70-12
Cooling System	Air
Transmission	CVT Automatic
Seat Height	780 mm
Wheelbase	1, 280 mm
