Sending Functions

2-20 ADVANCED OPERATION GUIDE

Image Quality

Select image quality suitable to the type of original.

The table below shows the quality options.

Use the procedure below to select the quality when sending scanned

originals.

Place the originals on the platen.

Press the Send key.

Press [Color/Image] and then [Original Image].

Select Image

Quality.

Press [OK].

Specify the destination, and press the Start key to start sending.

Item Detail

Text+Photo Text and photos together.

Text Only text, no photos.

Photo Only photos, no text.

for OCR For documents to be read by OCR.

Status 10/10/2007 10:10

Ready to send.

Destination

Add Shortcut

Select the original document type.

[for OCR]: For documents to be read by OCR.

Cancel OK

Text

Original Image

Enter Destination.

Text+Photo Photo

for OCR

Press [OK] to display

the image.
