8.4.2 CAN telegram counter (C0360)
C0360 counts for all parameter channels those telegrams that are valid for the controller.
The counters have a width of 16 bits. If a counter exceeds the value ’65535’, the counting
process restarts with ’0’.
Counted messages:
C0360 Meaning
Subcode 1 All telegrams sent
Subcode 2 All telegrams received
Subcode 3 Sent telegrams of CAN1_OUT
Subcode 4 Telegrams sent from CAN2_OUT
l Always "0"; channel is not used!
Subcode 5 Telegrams sent from CAN3_OUT
l Always "0"; channel is not used!
Subcode 6 Telegrams sent from parameter data channel 1
Subcode 7 Telegrams sent of parameter data channel 2
Subcode 8 Telegrams received from CAN1_IN
Subcode 9 Telegrams received from CAN2_IN
l Always "0"; channel is not used!
Subcode 10 Telegrams received from CAN3_IN
l Always "0"; channel is not used!
Subcode 11 Telegrams received from parameter data channel 1
Subcode 12 Telegrams received of parameter data channel 2
