Function library
DCTRL
Setting TRIP (TRIP−SET)
12

298
EDBCSXS064 EN 4.0
12.17.4 Setting TRIP (TRIP−SET)
This function sets TRIP" in the drive and indicates "External error" (error message "EEr").
ƒ The function can be controlled via the following inputs (OR’d):
– Control word "CAN1In−DctrlCtrl" bit 10 of CAN1In function block
– Control word "AIF1In−DctrlCtrl" bit 10 of AIF1In function block
– C0135/10 (control word for networking via AIF)
– Signal "DCTRL−TripSet1" ... "DCTRL−TripSet4" (ANDed, TRUE = set TRIP)
ƒ C0136/1 indicates the control word C0135.
ƒ The response to TRIP can be set via C0581.
Code Possible settings IMPORTANT
No. Designation Lenze/
{Appl.}
Selection
C0581 MONIT EEr 0
Fault response − external fault
monitoring "ExternalFault" (EEr)
 298
0 TRIP
1 Message
2 Warning
3 Off
4 FAIL−QSP
12.17.5 Resetting TRIP (TRIP−RESET)
This function resets an upcoming TRIP, provided that the cause of malfunction has been
eliminated. If the cause of malfunction is still active, there will be no reaction.
ƒ The function can be controlled via the following inputs (OR’d):
– Control word "CAN1In−DctrlCtrl" bit 11 of CAN1In function block
– Control word "AIF1In−DctrlCtrl" bit 11 of AIF1In function block
– C0135/11 (control word for networking via AIF)
– Signal "DCTRL−TripReset1" and "DCTRL−TripReset2" (ANDed, set TRUE = TRIP)
ƒ C0136/1 indicates the control word C0135.
 Note!
The function is only carried out by a FALSE−TRUE edge of the signal resulting
from the OR operation.
If one input is assigned to TRUE, a FALSE−TRUE edge cannot occur.
