Lenze ECSES Series User Manual

Monitoring functions Overview of monitoring functions
9

194
EDBCSXS064 EN 4.0
9.2 Overview of monitoring functions
Monitoring Possible fault responses
l Lenze setting
ü Can be set
Fault message Description Source
Code TRIP Message Warning Fail−QSP Off
x071 CCR System fault Internal l
x091 EEr External monitoring (activated via DCTRL) FWM C0581 l ü ü ü ü
x191 HSF Internal error Internal l
Voltage supply
1020 OU Overvoltage in the DC bus (C0173) MCTRL l
1030 LU Undervoltage in the DC bus(C0174) MCTRL l
0070 U15 Undervoltage of internal 15 V voltage supply Internal l
0107 H07 Internal fault (power section) Internal l
Communication
x041 AP1 Internal fault (signal processor) Internal l
x061 CE0 Communication error on the automation interface (AIF) AIF C0126 ü ü l
x062 CE1 Communication error on the CAN1_IN process data input object
(monitoring time adjustable via C0357/1)
CAN1_IN C0591 ü ü l
x063 CE2 Communication error on the CAN2_IN process data input object
(monitoring time adjustable via C0357/2)
CAN2_IN C0592 ü ü l
x064 CE3 Communication error on the CAN3_IN process data input object
(monitoring time adjustable via C0357/3)
CAN3_IN C0593 ü ü l
x065 CE4 BUS−OFF state CAN bus at interface X4 (CAN)
(too many faulty telegrams)
CAN C0595 ü ü l
x066 CE5 Communication error of the gateway function (C0370, C0371) via CAN bus
at interface X4 (CAN)
CAN C0603 ü ü l
x122 CE11 Communication error on the CANaux1_IN process data input object ( time
monitoring adjustable via C2457/1)
CANaux1_IN C2481 ü ü l
x123 CE12 Communication error on the CANaux2_IN process data input object ( time
monitoring adjustable via C2457/2)
CANaux2_IN C2482 ü ü l
x124 CE13 Communication error on the CANaux3_IN process data input object ( time
monitoring adjustable via C2457/3)
CANaux3_IN C2483 ü ü l
x125 CE14 BUS−OFF state CAN bus at interface X14 (CAN−AUX)
(too many faulty telegrams)
CANaux C2484 ü ü l
x: 0 = TRIP, 1 = message, 2 = warning, 3 = FAIL−QSP
1)
Adjustable in the DDS under Project  Exceptional handling
2)
For ECSxA... only
