Appendix
Overview of accessories
13
468
EDBCSXS064 EN 4.0
13.5.7 RFI filters
According to the application, different measures for reducing the mains current and for
radio interference suppression are required on the supply side for servo systems. As a rule,
these measures are not mandatory, but protect the universal application of a servo system.
Lenze offers a built−on filter for each power supply module for the interference level A. The
RFI filters are designed for the ECS power supply module assigned and up to 10 axes with
a motor cable length of 25 m each (Lenze system cable). The interference level A is
observed as long as the motor cable length per axis module is 25 m at a maximum (Lenze
sytem cables) and the number of the ECS axis modules is maximally 10.
RFI filter type ECS power supply module type
ECSZZ020X4B
ECSxE012
ECSxE020
ECSZZ040X4B ECSxE040
Type of RFI filter U [V] I [A] P
loss
[W] Weight [kg]
ECSZZ020X4B
3/PE AC 500 V
at 50 ... 60 Hz
16 6.2
3.0
ECSZZ040X4B 32 9.3
U Rated mains voltage
I Rated mains current
P
loss
Power loss
