Appendix
Selection lists for signal linking
List of the analog signal sources
13
437
EDBCSXS064 EN 4.0
13.2.2 List of the analog signal sources
Symbol in signal flow diagrams:
4
Selection No. Signal Keypad display Variable for Global Drive Oscilloscope (GDO)
2 FIXED100% FIXED100% gC_wPos16384
3 FIXED−100% FIXED−100% gC_wNeg16384
10 AIF1In−DctrlCtrl AIF1−Dctrl AIF1_wDctrlCtrl
11 AIF1In−W1 AIF1In−W1 AIF1_nInW1_a
12 AIF1In−W2 AIF1In−W2 AIF1_nInW2_a
13 AIF1In−W3 AIF1In−W3 AIF1_nInW3_a
14 AIF2In−W1 AIF2In−W1 AIF2_nInW1_a
15 AIF2In−W2 AIF2In−W2 AIF2_nInW2_a
16 AIF2In−W3 AIF2In−W3 AIF2_nInW3_a
17 AIF2In−W4 AIF2In−W4 AIF2_nInW4_a
18 AIF3In−W1 AIF3In−W1 AIF3_nInW1_a
19 AIF3In−W2 AIF3In−W2 AIF3_nInW2_a
20 AIF3In−W3 AIF3In−W3 AIF3_nInW3_a
21 AIF3In−W4 AIF3In−W4 AIF3_nInW4_a
23 CAN1In−DctrlCtrl CAN1−Dctrl CAN1_wDctrlCtrl
24 CAN1In−W1 CAN1In−W1 CAN1_nInW1_a
25 CAN1In−W2 CAN1In−W2 CAN1_nInW2_a
26 CAN1In−W3 CAN1In−W3 CAN1_nInW3_a
27 CAN2In−W1 CAN2In−W1 CAN2_nInW1_a
28 CAN2In−W2 CAN2In−W2 CAN2_nInW2_a
29 CAN2In−W3 CAN2In−W3 CAN2_nInW3_a
30 CAN2In−W4 CAN2In−W4 CAN2_nInW4_a
31 CAN3In−W1 CAN3In−W1 CAN3_nInW1_a
32 CAN3In−W2 CAN3In−W2 CAN3_nInW2_a
33 CAN3In−W3 CAN3In−W3 CAN3_nInW3_a
34 CAN3In−W4 CAN3In−W4 CAN3_nInW4_a
35 CANSync−Deviation CANSync−De CAN_nSyncDeviation
36 DCTRL−Stat DCTRL−Stat DCTRL_wStat
37 DCTRL−FaultNumber DCTRL−FNr DCTRL_wFaultNumber
38 FCODE−C0017 FCODE−C17 FCODE_nC17_a
43 FCODE−C0037 FCODE−C37 FCODE_nC37_a
44 FCODE−C0108/1 FC−C108_1 FCODE_nC108_1_a
45 FCODE−C0108/2 FC−C108_2 FCODE_nC108_2_a
46 FCODE−C0109/1 FC−C109_1 FCODE_nC109_1_a
47 FCODE−C0109/2 FC−C109_2 FCODE_nC109_2_a
48 FCODE−C0141 FC−C141 FCODE_nC141_a
49 FCODE−C0472/1 FC−C472_1 FCODE_nC472_1_a
50 FCODE−C0472/2 FC−C472_2 FCODE_nC472_2_a
51 FCODE−C0472/3 FC−C472_3 FCODE_nC472_3_a
52 FCODE−C0472/4 FC−C472_4 FCODE_nC472_4_a
53 FCODE−C0472/5 FC−C472_5 FCODE_nC472_5_a
54 FCODE−C0472/6 FC−C472_6 FCODE_nC472_6_a
55 FCODE−C0472/7 FC−C472_7 FCODE_nC472_7_a
56 FCODE−C0472/8 FC−C472_8 FCODE_nC472_8_a
