13.2 Selection lists for signal linking
13.2.1 List of the digital signal sources
Symbol in signal flow diagrams:
3
Selection No. Signal Keypad display Variable for Global Drive Oscilloscope (GDO)
2 FIXED 1(TRUE) FI 1 / TRUE gC_bTrue
10 AIF−bCe0CommErr AIF−Ce0 AIF_bCe0CommErr_b
11 AIF−bFieldBusStateBit0 AIF−Bit0 AIF_bFieldBusStateBit0_b
12 AIF−bFieldBusStateBit1 AIF−Bit1 AIF_bFieldBusStateBit1_b
13 AIF−bFieldBusStateBit2 AIF−Bit2 AIF_bFieldBusStateBit2_b
14 AIF−bFieldBusStateBit3 AIF−Bit3 AIF_bFieldBusStateBit3_b
15 AIF−bFieldBusStateBit4 AIF−Bit4 AIF_bFieldBusStateBit4_b
16 AIF−bFieldBusStateBit5 AIF−Bit5 AIF_bFieldBusStateBit5_b
17 AIF−bFieldBusStateBit6 AIF−Bit6 AIF_bFieldBusStateBit6_b
18 AIF−bFieldBusStateBit7 AIF−Bit7 AIF_bFieldBusStateBit7_b
19 AIF1In−Ctrl.Quickstop_B3 AIF1−CB3 AIF1_bCtrlQuickstop_b
20 AIF1In−Ctrl.Disable_B8 AIF1−CB8 AIF1_bCtrlDisable_b
21 AIF1In−Ctrl.CInhibit_B9 AIF1−CB9 AIF1_bCtrlCInhibit_b
22 AIF1In−Ctrl.TripSet_B10 AIF1−CB10 AIF1_bCtrlTripSet_b
23 AIF1In−Ctrl.TripReset_B11 AIF1−CB11 AIF1_bCtrlTripReset_b
24 AIF1In−Ctrl.Bit0 AIF1−CB0 AIF1_bCtrlB0_b
25 AIF1In−Ctrl.Bit1 AIF1−CB1 AIF1_bCtrlB1_b
26 AIF1In−Ctrl.Bit2 AIF1−CB2 AIF1_bCtrlB2_b
27 AIF1In−Ctrl.Bit4 AIF1−CB4 AIF1_bCtrlB4_b
28 AIF1In−Ctrl.Bit5 AIF1−CB5 AIF1_bCtrlB5_b
29 AIF1In−Ctrl.Bit6 AIF1−CB6 AIF1_bCtrlB6_b
30 AIF1In−Ctrl.Bit7 AIF1−CB7 AIF1_bCtrlB7_b
31 AIF1In−Ctrl.Bit12 AIF1−CB12 AIF1_bCtrlB12_b
32 AIF1In−Ctrl.Bit13 AIF1−CB13 AIF1_bCtrlB13_b
33 AIF1In−Ctrl.Bit14 AIF1−CB14 AIF1_bCtrlB14_b
34 AIF1In−Ctrl.Bit15 AIF1−CB15 AIF1_bCtrlB15_b
35 AIF1In−Bit0 AIF1−Bit0 AIF1_bInB0_b
36 AIF1In−Bit1 AIF1−Bit1 AIF1_bInB1_b
37 AIF1In−Bit2 AIF1−Bit2 AIF1_bInB2_b
38 AIF1In−Bit3 AIF1−Bit3 AIF1_bInB3_b
39 AIF1In−Bit4 AIF1−Bit4 AIF1_bInB4_b
40 AIF1In−Bit5 AIF1−Bit5 AIF1_bInB5_b
41 AIF1In−Bit6 AIF1−Bit6 AIF1_bInB6_b
42 AIF1In−Bit7 AIF1−Bit7 AIF1_bInB7_b
43 AIF1In−Bit8 AIF1−Bit8 AIF1_bInB8_b
44 AIF1In−Bit9 AIF1−Bit9 AIF1_bInB9_b
45 AIF1In−Bit10 AIF1−Bit10 AIF1_bInB10_b
46 AIF1In−Bit11 AIF1−Bit11 AIF1_bInB11_b
47 AIF1In−Bit12 AIF1−Bit12 AIF1_bInB12_b
48 AIF1In−Bit13 AIF1−Bit13 AIF1_bInB13_b
49 AIF1In−Bit14 AIF1−Bit14 AIF1_bInB14_b
50 AIF1In−Bit15 AIF1−Bit15 AIF1_bInB15_b
