Function library
FIXED (output of constant signals)
12
312
EDBCSXS064 EN 4.0
12.23
FIXED (output of constant signals)
Function
This function block outputs fixed values to provide easy programming in the standard
calculation of percentage (100 % = 16384) of the drive technology.
FIXED
2
3
2
FIXED
100%
FIXED
-100%
FIXED
1(True)
ECSXA262
Fig. 12−24
FIXED function block (output of constant signals)
