Technical Information
15
CVA 4062/CVA 4066/CV
A 4068 Coffee Sy
stems
2 Interior
View
Figure D-2:
Interior View of Appliance
1
Main switch
7
Water tank
2
Storage drawer
8
Brew unit
3
Ground-coffee chute
9
Waste container
4
Grind adjustment lever
10
Main dispenser connector (connects the
brew unit to t
he main dispenser)
5
Beans container
11
Stainless-steel milk container
6
Drip tray with no-spi
ll grid for transport
14
16
