Technical Information
70
CVA 4062/CVA 4066/CVA 4068 Coffee Systems
Figure 051-17: Flow Meter
9. Disconnect the silicone hoses from the flow meter; see Figure 051-18.
10. Disconnect the flow meter wiring harness.
11. Remove the flow meter from its plastic support. See Figure 051-18, Item 2.
Figure 051-18: Flow Meter (1) and Plastic Support (2)
Warning!
In order to avoid possible water system faults (e.g., clogging or blocking
of valves), grease, oil or other slip lubricants should never be used when
assembling and installing water system parts.
