Technical Information
40
CVA 4062/CVA 4066/CV
A 4068 Coffee Sy
stems
Figure 030-9:
Drain Position, Rea
r View
Figure 030-10:
Drain Position, Front View
3 Fault
Repair
3.1
Coffee Grounds Next to the Brew Unit
Symptom:
After approximately 5 coffee servings, there is a large amount of coffee grounds next
to the brew unit.
Cause:
The grind amount compensation is set to maximum. See the function description for
grind amount compensation, Section 030-2.1.2.
