Technical Information
30
CVA 4062/CVA 4066/CVA 4068 Coffee Systems
To deactivate the optical interface again, depending on the selected remedy:
1. Quit the machine service mode, or
2. Briefly disconnect the machine from the power supply again, or
3. Log on the machine to the RemoteVision system.
After a maximum of 1 minute, the RemoteVision system can be used again.
3.2 RemoteVision InfoControl: Incorrect Language Set
See DTD for XIC 2000.
3.3 RemoteVision InfoControl: Time of Day Setting Varies
See DTD for XIC 2000.
3.4 RemoteVision InfoControl: Buzzer Inoperative
See DTD for XIC 2000.
3.5 RemoteVision InfoControl: Data Transfer Interference
See DTD for XIC 2000.
3.6 RemoteVision InfoControl: Mobile Receiver Display Faulty
See DTD for XIC 2000.
3.7 Machine Runs Automatically and Chirps When the Door is Opened
Cause:
Faulty grounding of the fascia panel. The ground spring in the upper door hinge does
not have contact with the stainless-steel panel.
Remedy:
Note:
The fascia panel is coated with Cleansteel and is thus nonconductive, so
measure resistance on the edge of the panel.
1. Use an ohmmeter to measure the resistance between the housing edges and
ground.
2. Release the top hinge on the door.
3. Move the spring back and forth. The spring should press against the stainless-steel
fascia.
4. Secure the hinge.
5. Check the resistance again.
4 Service
4.1 Control/Display Electronic EPWZ (N5) Removal
1. Disconnect the appliance from power.
2. Turn off the water supply (CVA 4066).
3. Open the door.
4. Remove the milk container.
5. Remove the three right cover retaining screws (T10); see Figure 025-2, Item 1.
