Technical Information
46
CVA 4062/CVA 4066/CVA 4068 Coffee Systems
2 Function
2.1 Adjusting the Grinder Setting
Push the slide control to the left for a finer grind or to the right for a coarser grind. See
Figure 040-1. You should be able to feel the adjustment settings when moving the
slide control.
If the slide control will not move, close the machine and dispense a cup of coffee, then
try to move the slide control again
Figure 040-1: Grinder Adjustment
2.2 Filling Ground Coffee
A funnel for ground coffee is provided in case the customer would like to prepare a
different coffee type, such as decaffeinated coffee.
1. Pull the container for the ground coffee out of the appliance and lift the funnel lid
(Figure 040-2, Item 1).
2. Place one spoonful of ground coffee into the funnel (Figure 040-2, Item 2), using
the supplied spoon, and close the lid.
3. Push the container into the appliance and close the door.
Figure 040-2: Ground Coffee Funnel and Lid
For more information, see "Preparing drinks - Coffee and espresso prepared from
ground coffee" in the operating manual.
4 Service
4.1 Grinder (M25) Removal
1. Remove the appliance from its cabinet. See Section 010-4.1.
2. Carefully remove the top cover retaining screws. The larger (T20) screws have
metal washers underneath that can easily be misplaced.
3. Remove the top cover.
4. Remove the three service door retaining screws; see Figure 040-3, Item 1.
