Technical Information
49
CVA 4062/CVA 4066/CVA 4068 Coffee Systems
14. Remove the T10 screw securing the ground coffee chute to the grinder (Figure
040-7, Item A) and remove the chute.
Figure 040-7: Grinder Retaining Screws
15. Remove the grinder halfway.
16. Disconnect all electrical connections to the grinder.
17. Carefully remove the grinder from the appliance.
Note:
When re-installing the grinder, first install the rubber bushings in their notches
on the grinder, then slide the brass rods into place.
