Mindray BeneHeart D2 User Manual

Defibrillator/Monitor Operator’s Manual 21 - 5
21.6.4 Pacer Setup Menu
21.6.5 CPR Setup Menu
21.6.6 ECG Setup Menu
Voice Volume High, Med, Low High Sets the volume level for voice
prompts in the AED mode.
Voice Prompt Interval Off, 30s, 60s, 90s, 120s, 150s,
180s
30s Sets the interval for voice
prompts in the AED mode.
Voice Recording On, Off Off Sets whether to enable the
voice recording in the AED
mode.
Initial CPR Time Off, 30 s, 60 s, 90 s, 120 s, 150
s, 180 s
Off Sets the initial CPR time after
the AED mode is entered.
Menu Item Options/Range Default Description
Menu Item Options/Range Default Description
Pacer Rate 30 to 210 ppm 70 ppm Sets the delivered rate of paced
pulses.
Pacer Output 0 to 200 mA 30 mA Sets the paced pulses duration.
Pacer Output Step 1 mA, 2 mA, 5 mA 5 mA Sets the step of paced pulses
duration.
Default Pacer Mode Demand Mode, Fixed Mode Demand Mode Sets the pacer mode when
entering the Pacer mode.
Pacer Pulse 20 ms, 40 ms 20 ms Sets the pacer output setting at
which pace pulses are delivered.
Menu Item Options/Range Default Description
CPR Metronome On, Off On Sets whether the compression
are performed at the setting of
[CPR Mode]
Voice Prompts On, Off On Sets whether voice prompts are
provided when using a CPR
sensor.
CPR Filter On, Off Off Sets whether to enable the CPR
filter when performing CPR.
Menu Item Options/Range Default Description
ECG Standard AHA, IEC AHA Sets the ECG standard
according to the leadwires you
are using.
Notch Filter 50 Hz, 60 Hz 50 Hz The notch filter removes the line
frequency interference.Sets
notch filter frequency according
to the power line frequency of
your country.
ECG Bandwidth Monitor, Therapy Therapy Sets the filter frequency for 3-/5-
lead ECG cable.
