A - 2 Defibrillator/Monitor Operator’s Manual
A.1.5 Interface Specifications
A.1.6 Signal Outputs Specifications
A.2 Defibrillator Specifications
USB connector Connects USB flash memory
RJ45 connector Connects standard network cable.
Multifunctional connector Connects a cable for analog output or a cable for synchronized
cardioversion.
Multifunctional connector
Standard Meets the requirements of EN60601-1 for short-circuit protection and
leakage current
ECG Analog Output (only ECG lead set)
Bandwidth
(-3 dB; reference frequency: 10 Hz)
Diagnostic mode: 0.05 to 150 Hz
Monitor mode: 0.5 to 40 Hz
Therapy mode: 1 to 20 Hz
Maximum QRS delay 25 ms (in diagnostic mode, and with Notch off)
Sensitivity 1 V/mV ±5%
Pace enhancement Signal amplitude: V
oh
≥2.5V
Pulse width: 10ms±5%
Signal rising and falling time: ≤100μs
Synchronous input
Input signal range 0 to 5V (TTL level)
Input impedance ≥10 kΩ
Pulse width >5 ms
Alarm output
Alarm delay time from the equipment to
other remote equipment
The alarm delay time from the equipment to other remote equipment is ≤4
seconds, measured at the equipment signal output connector.
Alarm signal sound pressure level range 45 db(A) to 85 db(A) within a range of one meter
Standards Meet standards of IEC 60601-2-4
Defibrillation mode Manual defib, synchronized cardioversion, AED
Defibrillation waveform Biphasic truncated exponential (BTE) waveform, auto-compensation
according to patient impedance
Defibrillation electrodes External paddles set coming with pediatric paddles included, multifunction
electrode pads and internal paddles
Controls and indicators on external
paddles
Charge butto
n, Shock buttons, Energy Select buttons, charge done indicator
Shockable rhythm analysis time < 8s
Range of selected energy
External defibrillation 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 15, 20, 30, 50, 70, 100, 150, 170, 200, 300, 360 J
Internal defibrillation 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 15, 20, 30, 50 J
Patient impedance range
External defibrillation 25 to 300 Ω
