Mindray BeneHeart D2 User Manual

Defibrillator/Monitor Operator’s Manual A - 1
A Specifications
A.1 General Specifications
A.1.1 Safety Specifications
The equipment is classified, according to IEC 60601-1:
A.1.2 Physical Specifications
A.1.3 Display Specifications
A.1.4 Audio Indicators
Type of protection against electrical shock Class I, equipment energized from an external and internal electrical power
source.
If you suspect the integrity of the external protective earthing or the
protective earthing wire, you should run the equipment on internal
electrical power supply (battery).
Degree of protection against electric
shock
Type BF defibrillation proof for CO
2
monitoring and external defibrillation.
Type CF defibrillation proof for ECG, SpO
2
, NIBP, internal defibrillation and
CPR sensor.
Mode of operation Continuous
Degree of protection against harmful
ingress of solid
IP4X
Degree of protection against harmful
ingress of water
IPX4 (when running on battery)
IPX1 (when running on AC power supply)
Degree of mobility Portable
Size (Width × depth × height) 288 mm×203 mm×275 mm
Maximum weight 6.1 kg, including a battery, external paddles and 3-leadwire.
Type TFT Color LCD
Size 7 inch
Resolution 800×480 pixels
Viewed waveforms 3 at maximum
Wave viewing time 16s at maximum (ECG)
Speaker Gives alarm tones (45 to 85 dB), key tones, QRS tones
Supports PITCH TONE and multi-level tone modulation
Alarm tones comply with IEC60601-1-8.
Audio signal Alarm tone: ISO mode with frequency of 600 Hz
QRS tone: short beep with frequency of 650 Hz
Charge tone: long beep with frequency of 400 Hz
Charge done tone: double beeps with frequency of 870 Hz
Key tone: short beep with frequency of 1000 Hz
