ECG/RESP Monitoring
11-4
11.1.2 ECG Parameters
Figure 11-2 ECG Parameters
The parameters related to ECG are displayed to the right of the ECG waveforms as
shown above. The heartbeat indicator flashes in the same rate with the patient’s
heartbeat. On the right of the heart rate numeric are the ON/OFF status or value of
PACE, ST1, ST2, PVCs and NOTCH.
ECG label
Heart rate value
Heartbeat icon
Alarms Disabled icon
