ECG/RESP Monitoring
11-12
11.3 ECG Setup Menu
Select the ECG label in the parameter windows. The following menu appears.
Figure 11-7 ECG SETUP Menu
In this menu, you can perform the following settings:
îš„ HR ALM
Heart rate alarm on/off status
ON: When a heart rate alarm occurs, the monitor gives alarm
indications and stores the alarm;
OFF: When a heart rate alarm occurs, the monitor neither gives
alarm indications nor stores the alarm;
When OFF is selected, the
icon is displayed on the right of
the ECG label.
îš„ ALM LEV
Alarm level
Options: HIGH, MED and LOW.
îš„ ALM REC
Alarm recording
ON: When a heart rate alarm occurs, the monitor enables the
recording;
OFF: When a heart rate alarm occurs, the monitor does not
enable the recording.
îš„ ALM HI
Upper alarm limit
Determines the upper ECG alarm limit.
îš„ ALM LO
Lower alarm limit
Determines the lower ECG alarm limit.
To Next Page
