Appendices
20-5
A.4 Hardware Specifications
Physical
Size 318 × 270 × 137mm (width×height×depth)
Weight
Different due to different configurations
Standard configuration: 4.7kg
Maximum weight: ≤ 7.5kg
Display
Type Color TFT LCD
Size 10.4 inches (diagonal)
Resolution 800×600 pixels
Recorder
Type Thermal dot array
Horizontal resolution 160 dots/cm (at 25 mm/s recording rate)
Vertical resolution 80 dots/cm
Width of the recorder paper 50 mm
Length of the recorder paper 30 m
Recording rate 25 mm/s, 50 mm/s
Recorded waveforms 2
LED indicator
Alarm indicator 1 (yellow and red)
AC power indicator 1 (green)
Audio indicator
Speaker
Giving audio alarms, keypad tones, and heartbeat/pulse tone.
Supporting PITCH TONE and multi-level volume.
Audio alarms comply with EN475 and IEC60601-1-8.
Control
Control knob
1 knob, which can be rotated clockwise/counterclockwise or
pressed.
Button
7 buttons: POWER, MAIN, FREEZE, PAUSE, RECORD,
NIBP, MENU
