Chapter 5 Operation
123
VIDEO SYSTEM OTV-SI
5.15 Photography with the color video printer
(OEP-3/OEP-not available in some countries)
The image can be released using the remote control switches or the keyboard
(optional).
• When controlling the image directly from the OEP-3/OEP,
refer to the video printer’s instruction manual.
• To obtain sharp photographs without blurring, keep the
endoscope stationary when releasing the image.
Using the menu
1. Press the OEP-3’s or OEP’s MENU button and use the “”, “”, “ ” or
“ ” button to select “FUNCTION SETUP”.
2. Set “RM2 FUNC” to “C&PRINT mode” and “AUTO LIVE” to ON.
3. If the video monitor does not display the menu, press the remote control
switch for execution or for selection, the “F1”, “Enter”, “ ”, “ ”, “” or “”
key on the keyboard to display the menu.
4. Press the remote control switch for selection, the “” or “” key on the
keyboard and select “RELES” (see Figure 5.79).
Figure 5.79
To Next Page
