30
Chapter 3 Installation and Connection
VIDEO SYSTEM OTV-SI
3.3 Connection to the keyboard (optional)
• Always keep the cover on the keyboard. If liquid is spilled or
splashed onto the keyboard, it may be damaged.
• Always turn OFF this instrument when connecting or
disconnecting the keyboard. Otherwise, this instrument will
not receive input from the keyboard.
• Do not pull the keyboard cable with excessive force once it
has been connected to this instrument. Doing so may result
in connection failure or the inability of the OTV-SI to accept
input from the keyboard.
• Keep the HF equipment and ancillary cords as far away as
possible from the keyboard and its cord. If placed too close,
this instrument will not receive input from the keyboard.
1. Turn this instrument OFF.
2. Connect the keyboard as shown in Figure 3.3.
When installing the keyboard on the compact trolley (TC-C2),
refer to the compact trolley’s instruction manual.
To Next Page
