Olympus OTV-SI - 3.5 Connection to the color video printer

36
Chapter 3 Installation and Connection
VIDEO SYSTEM OTV-SI
Figure 3.8
3.5 Connection to the color video printer
(OEP-3/OEP-not available in some countries)
1. Turn this instrument and the OEP-3/OEP OFF.
2. Connect the cables to this instrument and the OEP-3 or OEP as shown in
Figure 3.9.
Output connector
VISY218
