Chapter 5 Operation
VIDEO SYSTEM OTV-SI
5.18 Air/water feed (type B only)
Air or water can be fed using the air feed switch on the front panel, the remote
control switches or the keyboard (optional).
 Using the air feed switch on the front panel
1. Connect the videoscope to the video connector socket and the output
connector and depress the air feed switch to feed air (see Figure 5.83).
Figure 5.83
2. Press the air feed switch to turn air feed ON and OFF.
3. Feed air and water following the instructions given in the videoscope’s
instruction manual.
 Using the menu
1. If the video monitor does not display the menu, press the remote control
switch for execution or for selection, the “F1”, “Enter”, “  ”, “  ”, “” or “”
key on the keyboard to display the menu.
2. Press the remote control switch for selection, the “” or “” key on the
keyboard and select “NEXT” (see Figure 5.6 on page 57).
3. Press the remote control switch for execution, the “Enter” or “  ” key on the
keyboard three times to display the menu bar shown in Figure 5.69 on
page 113.
Air feed switch
Air feed indicator
VISY218
