OMNI 4000/7000 Operations and Maintenance Guide – Rev F
a. In the Batch Control screen, enter
the adjustment amount in the Adjust
Batch Size field.
b. Click the Adjust Batch Size button to
update the batch size to the amount
you entered.
c. Click Apply to save your changes.
For liquid applications:
a. Click on the Batch Stack tab.
b. Double-click on the numbered row of the batch you need to adjust to open the Edit
Batch Stack window.
In the Edit Batch Stack window, enter the
new total amount in the Batch Size field.
Click Apply to save your changes and
update the size in the sequence list.
3.6.3 Batch Stack Control
In liquid applications, each independent flow Meter Run has a batch stack queue or sequence
that has one active running product with five additional slots for queueing future products for
batching. “Independent” batch stacks are useful when running different products simultaneously
on each Meter Run. This stack configuration allows six batches to be programmed into the flow
computer for each Meter Run.
In applications where multiple flow meters are running the same product simultaneously, a shared
“common” batch stack feature with one active product and 23 queue slots can be configured by
defining a Station that includes the individual flow meters. A maximum of two Stations can be
configured. A mix of independent and common batch stacks can be used in the flow computer.
You can enter a positive number to
increase the batch size or a
negative number to decrease the
batch size.
Unlike the Adjust Batch Size
option on the Batch Control
screen (Step 3), the Batch Size
field automatically changes the
entire batch to match the new
amount instead of adding or
subtracting anything.
