Expansion Instructions (CQM1/SRM1 Only) Section 2-1
2-1-1 CQM1 Expansion Instructions
The following 18 function codes can be used for expansion instructions: 17,
18, 19, 47, 48, 60, 61, 62, 63, 64, 65, 66, 67, 68, 69, 87, 88, and 89
The expansion instructions that can be used are listed below, along with the
default function codes that are assigned when the CQM1 is shipped. Instruc-
tions marked with a “*” are available only in CQM1-CPU4@-EV1 CPU Units.
With the CQM1, an instructions table can also be stored on Memory Cas-
settes when they are used. Exercise care when using a Memory Cassette that
has been used with another CQM1 or SRM1 and be sure the proper instruc-
tions table is present.
!Caution If pin no. 4 of the CQM1’s DIP switch is set to OFF, only expansion instructions
on the default instructions table can be used and the user-set instructions
table will be ignored. The default instructions table will also be set whenever
power is turned on, deleting any previous settings.
Make sure that pin 4 of the CPU Unit DIP switch is ON when reading a pro-
gram from the Memory Cassette that has a user-set expansion instructions
table. If pin 4 is OFF, the default instructions table will be used for expansion
instructions in programs read from a Memory Cassette. (In this case, the pro-
gram read from the Memory Cassette and the program on the Memory Cas-
sette will not match when the two are compared.)
2-1-2 SRM1 Expansion Instructions
The following 18 function codes can be used for expansion instructions: 17,
18, 19, 47, 48, 60, 61, 62, 63, 64, 65, 66, 67, 68, 69, 87, 88, and 89
The expansion instructions that can be used are listed below, along with the
default function codes that are assigned when the SRM1 is shipped.
Mnemonic Function code Mnemonic Function code Mnemonic Function code
ASFT 17 INT 89 ADBL* ---
TKY 18 HKY --- SBBL* ---
MCMP 19 FPD --- MBS* ---
RXD 47 SRCH --- DBS* ---
TXD 48 MAX --- MBSL* ---
CMPL 60 MIN --- DBSL* ---
INI 61 APR --- CPS* ---
PRV 62 LINE --- CPSL* ---
CTBL 63 COLM --- NEG* ---
SPED 64 SEC --- NEGL* ---
PULS 65 HMS --- ZCP* ---
SCL 66 SUM --- ZCPL* ---
BCNT 67 FCS --- XFRB* ---
BCMP 68 HEX --- PLS2* ---
STIM 69 AVG --- ACC* ---
DSW 87 PWM* --- SCL2* ---
7SEG 88 PID* --- SCL3* ---
Mnemonic Function code
ASFT 17
RXD 47
TXD 48
CMPL 60
