Special Math Instructions Section 5-22
!Caution If bit 14 of C is ON, values above #8000 are treated as negative numbers, so
the results will differ depending on the specified data type. Be sure that the
correct data type is specified.
Flags ER: Indirectly addressed DM word is non-existent. (Content of *DM word
is not BCD, or the DM area boundary has been exceeded.)
R
1
and R
1
+N–1 are not in the same data area.
EQ: ON when the maximum value is #0000.
5-22-2 FIND MINIMUM – MIN(––)
Limitations This instruction is available in the CQM1 only.
N must be BCD between 0001 to 9999.
R
1
and R
1
+N–1 must be in the same data area.
DM 6144 to DM 6655 cannot be used for D.
Description When the execution condition is OFF, MIN(––) is not executed. When the exe-
cution condition is ON, MIN(––) searches the range of memory from R
1
to
R
1
+N–1 for the address that contains the minimum value and outputs the min-
imum value to the destination word (D).
If bit 15 of C is ON, MIN(––) identifies the address of the word containing the
minimum value in D+1. The address is identified differently for the DM area:
1,2,3... 1. For an address in the DM area, the word address is written to C+1. For ex-
ample, if the address containing the minimum value is DM 0114, then
#0114 is written in D+1.
2. For an address in another data area, the number of addresses from the be-
ginning of the search is written to D+1. For example, if the address contain-
ing the minimum value is IR 114 and the first word in the search range is
IR 014, then #0100 is written in D+1.
If bit 14 of C is ON and more than one address contains the same minimum
value, the position of the lowest of the addresses will be output to D+1. The
position will be output as the DM address for the DM area, but as an absolute
position relative to the first word in the range for all other areas.
The number of words within the range (N) is contained in the 3 rightmost dig-
its of C, which must be BCD between 001 and 999.
R
1
: First word in range
IR, SR, AR, DM, HR, TC, LR
C: Control data
IR, SR, AR, DM, HR, TC, LR, #
Ladder Symbols Operand Data Areas
@MIN(––)
C
R
1
D
D: Destination word
IR, SR, AR, DM, HR, LR
MIN(––)
C
R
1
D
