199
Instruction Tables Section 5-6
PULS (@) 65 4 SET PULSES CQM1 and
CPM1A-@@CDT/CDT1 only
336
PWM (@) –– 4 PULSE WITH VARIABLE DUTY RATIO CQM1-CPU43-E/-EV1 only 345
RET 93 1 SUBROUTINE RETURN All 323
ROL (@) 27 2 ROTATE LEFT All 231
ROOT (@) 72 3 SQUARE ROOT CQM1 only 295
ROR (@) 28 2 ROTATE RIGHT All 232
RSET None 2 RESET All 202
RXD (@) 47 4 RECEIVE CQM1/SRM1 only 349
SBB (@) 51 4 BINARY SUBTRACT All 297
SBBL (@) –– 4 DOUBLE BINARY SUBTRACT CQM1-CPU4@-E/-EV1 only 301
SBN 92 2 SUBROUTINE DEFINE All 323
SBS (@) 91 2 SUBROUTINE ENTRY All 321
SCL (@) 66 4 SCALING CQM1 only 272
SCL2 (@) –– 4 SIGNED BINARY TO BCD SCALING CQM1-CPU4@-E/-EV1 only 274
SCL3 (@) –– 4 BCD TO SIGNED BINARY SCALING CQM1-CPU4@-E/-EV1 only 276
SDEC (@) 78 4 7-SEGMENT DECODER All 265
SEC –– 4 HOURS TO SECONDS CQM1 only 278
SET None 2 SET All 202
SFT 10 3 SHIFT REGISTER All 229
SFTR (@) 84 4 REVERSIBLE SHIFT REGISTER All 234
SLD (@) 74 3 ONE DIGIT SHIFT LEFT All 233
SNXT 09 2 STEP START All 210
SPED (@) 64 4 SPEED OUTPUT CQM1 and
CPM1A-@@CDT/CDT1 only
338
SRCH (@) –– 4 DATA SEARCH CQM1 only 346
SRD (@) 75 3 ONE DIGIT SHIFT RIGHT All 233
STC (@) 40 1 SET CARRY All 285
STEP 08 2 STEP DEFINE All 210
STIM (@) 69 4 INTERVAL TIMER All 218
STUP –– 3 CHANGE RS-232C SETUP SRM1 only 352
SUB (@) 31 4 BCD SUBTRACT All 286
SUBL (@) 55 4 DOUBLE BCD SUBTRACT All 292
SUM (@) –– 4 SUM CQM1 only 311
TCMP (@) 85 4 TABLE COMPARE All 249
TIM None 2 TIMER All 213
TIMH 15 3 HIGH-SPEED TIMER All 217
TKY (@) 18 4 TEN KEY INPUT CQM1 only 356
TRSM 45 1 TRACE MEMORY SAMPLE CQM1-CPU4@-E/-EV1 only 323
TXD (@) 48 4 TRANSMIT CQM1/SRM1 only 350
WSFT (@) 16 3 WORD SHIFT All 230
XCHG (@) 73 3 DATA EXCHANGE All 240
XFER (@) 70 4 BLOCK TRANSFER All 239
XFRB (@) –– 4 TRANSFER BITS CQM1-CPU4@-E/-EV1 only 247
XNRW (@) 37 4 EXCLUSIVE NOR All 318
XORW (@) 36 4 EXCLUSIVE OR All 318
ZCP –– 4 AREA RANGE COMPARE CQM1-CPU4@-E/-EV1 only 256
ZCPL –– 4 DOUBLE AREA RANGE COMPARE CQM1-CPU4@-E/-EV1 only 258
Mnemonic Code Words Name CPU Units Page
