10.11
Battery and Electrical Systems
10
SECURITY SYSTEM
Security System: Overview
An optional security feature is available on all 2012 and
later Pro-Ride snowmobiles which is enabled by an
authorized Polaris dealer using Digital Wrench®. The
security feature allows the operator to lock the ECU to
prevent unauthorized use. When security is locked the
ECU will prevent clutch engagement by limiting engine
speed to 3500 RPM.
NOTE: If the engine is running and security is locked,
t
he ECU will shut the engine off when the engine
temperature is above 120°F (49°C) for 60 seconds.
Security System: Digital Wrench® Enable
Use Digital Wrench® to enable the security function in the
ECU. The following list of tools is required to enable the
security function:
• PC/Laptop equipped with Digital Wrench® and
a
ssociated snowmobile SmartLink communication
cables
• Fully Charged 12 VDC Battery
• Chassis Power-Up Harness: PS-47296-A
• Dual Power-Up Adapter: PS-50805
• Internet connection to Polaris reflash authorization
si
te
Chassis Power-Up Harness an
d Dual PWR/Fuel Pump
Prime Adapter
Digital Wrench® SmartLink Module/Communication
Cable
s
The security enable process has to be performed when:
• User wants security function turned on
• ECU has been reflashed with new reflash fileset
• Installing a new ECU
To enable the security function:
1. Open the left side engine compartment door and
locate
the Digital Wrench® diagnostic plug, ECU
power plug, and DC power plug.
2. Connect the dual power-up adapter to the chassis
po
wer-up harness. Attach one of the dual power-up
connectors to the ECM PWR plug, and the other to the
DC PWR plug. Connect the alligator clamps to a fully
charged 12 VDC battery.
CHASSIS POWER-UP HARNESS
PS-47296-A
DUAL PWR/FUEL PUMP PRIME
PS-50805
To Next Page
