Polaris 600 RUSH 2010 User Manual

1.49
General Information
1
NOTE: * = Rider weight in everyday clothing.
** = From full soft (CCW) position.
General
Width (in/cm) 48 / 121.9
Length (in/cm) 108 / 274
Height (in/cm) 46 / 117
Estimated Dry Weight (lb/kg) 469 / 212
Fuel (Gallons / Liters) 11 / 41.6
Oil (Quarts / Liters) 3.8 / 3.6
Cooling System Capacity(Qts/ L) 5 / 4.7
Brake Fluid DOT 4
Drive Belt
Part Number
Width (inches / cm)
Side Angle
Circumference (inches / cm)
Center Distance (inches / cm)
3211122
1.460
/ 3.7
26°
46.77 / 118.8
11.5 / 29.2
Chaincase
Center Distance (inches)
Top Gear (Stock)
Bottom Gear (Stock)
Chain (Stock)
Gear Lube
Capacity (oz / ml)
Reverse System
7.53
22
40
72
Po
laris Synthetic (80W)
9 / 266
PERC
Electrical
Alternator Output
Operating Voltage
Watts @ 13.5 VDC (Total)
13.5 - 14.5 VDC
40
0
Ignition Timing
18° @1700 RPM
Co
olant Temp = 120° F (49° C)
Spark Plug Gap in.(mm) .027 (.70)
Spark Plug NGK BPR9ES
Front Suspension
Suspension Type
PRO-RIDE (Fixed Camber)
Shocks
BASE/Adventure
PRO-R

Fox HPG w/IFP
Walker Evans Needle Piggyback
16 Click Compression Adjustable
Factory Setting** = 6
IFS Spring Rate
lbs/in (N/mm)
80 (14)
Preload - Inches (cm)
Base/Adventure
PRO-R
3.75 (9.52)
3.
0 (7.6)
Travel-Inches (cm) 9 (22.9)
Ski Center Distance
Inches (cm)
Setup Width
42.5 (108)
41
.52 (105)
Toe Out - Inches (mm) 0 -1/8 (0
- 3)
Rear Suspension
Suspension Type PRO-RIDE Progressive
Front Track Shock
(FTS)
Base/Adventure
PRO-R


Fox HPG w/IFP
W
alker Evans w/Remote
Reservoir
16 Click Compression Adjustable
Factory Setting** = 2
FTS Spring Rate
lbs/in (N/mm)
120 - 310 (21 - 54.25)
FTS Spring Preload
Inches (cm)
1.375 (3.49)
Rear Track Shock
(RTS)
Base
Adventure/PRO-R


Fox HPG w/IFP
Walker Evans Needle
w/Remote Reservoir
16 Click Compression Adjustable
Factory Setting** = 4
Standard RTS Spring
Rider Weight*
120 - 260lbs.
Rate lbs/in (N/mm)
PN: 7043160-133
1
50 (26.25)
LW RTS Spring
Rider Weight*
90 - 150lbs.
Rate lbs/in (N/mm)
PN: 7041575-385
1
20 (21)
HD RTS Spring
Rider Weight*
240 - 335+lbs.
Rate lbs/in. (N/mm)
PN: 7043585-385
26
0 (45.5)
RTS Spring
Rider / Weight Setting
Spring length set to rider weight
u
sing adjustment gauge.
STD Gauge PN: 9923267
STD gauge supplied with vehicle.
LW and HD springs - Use tape
measure and RTS Spring Guide
Table located in the Steering/
Suspension Chapter.
Rear Travel
Inches (cm)
14 (35.6)
