1.65
General Information
1
NOTE: * = Rider weight with gear.
Track
Width - Inches (cm) 15 (38)
Length - Inches (cm)
155 (393.7)
16
3 (414)
Pitch
Plies
2.86
1
Lug Height - Inches (cm) 2.4 (6.1) Series 5.1
Track Tension 3/8- 1/2(1
.0 - 1.3cm)
Electrical
Alternator Output
Operating Voltage
Watts @ 13.5 VDC
(T
otal)
13.5 - 14.5 VDC
40
0
Ignition Timing
18° @1700 RPM
Coolant Temp = 120° F (49° C)
Spark Plug Gap
in.(mm)
.027 (.70)
Spark Plug NGK BPR9ES
Front Suspension
Suspension Type PRO-RIDE RMK Adjustable
Shocks Walker Evans HPG w/IFP
IFS Spring Rate
lbs/in (N/mm)
100 (17.4)
IFS Spring Installed
Le
ngth - Inches (cm)
10.25 (26)
Front Vertical Travel
Inches (cm)
9 (22.9)
Ski Center Distance
Inches (cm)
Setup Width
39-40-41 (99.1-101.6-104.1)
36
.26 (92)
Measured inside of spindles.
Camber Inches (cm) 1.95 0.31 (
4.3 .8)
Toe Out - Inches
(m
m)
0 -1/8 (0 -
3)
Rear Suspension
Suspension Type RMK Coil-Over 155/163
Front Track Shock
(FTS)
Walker Evans HPG w/IFP
FTS Spring Rate
lbs/in (N/mm)
150 (26.25)
FTS Spring Installed
L
ength
Inches (cm)
8.50 (21.6)
Rear Track Shock
(RTS)
Walker Evans HPG w/IFP
Standard RTS Spring
Rate lbs/in (N/mm)
Installed Length In. (cm)
(Track off ground)
Rider Weight*
<160lbs./72kg
160-220lbs./72-99kg
220-280lbs./99-127kg
280-340lbs./127-154kg
PN: 7043714-133
2
10 (36.75)
10-3/4" (27.3)
10-3/8" (26.3)
10-1/8" (25.7)
9-3/4" (24.8)
CAUTION: Do not adjust STD
spring length greater than
11.0" or less than 9-3/4".
HD RTS Spring
Rate lbs/in. (N/mm)
Installed Length In. (cm)
(Track off ground)
Rider Weight*
250-300lbs./113-136kg
300-350lbs./136-159kg
PN: 7043740-067
2
50 (43.75)
10-1/8" (25.7)
10" (25.4)
CAUTION: Do not adjust HD
spring length greater than
10-7/8" or less than 9-7/8".
Rear Travel
Inches (cm)
16 (40.6)
