1.8
9924864 - 2012-2014 SPORTSMAN 800 / 6X6
© Copyright 2013 Polaris Sales Inc.
Sportsman 800 EFI BIG BOSS 6x6
ENGINE
PLATFORM
POLARIS TWIN
CYLINDER
Engine Model Number
EH076OLE
Engine Displacement
760cc
Number of Cylinders
2
Bore & Stroke (mm)
80 x 76.5 mm
Compression Ratio
11:1
Compression Pressure 150-200 psi
Engine Idle Speed
1150 ± 100 RPM
Engine Max Operating
Rpm
6600 Rpm ± 200 Rpm
Cooling System / Capacity Liquid - 3.6 qt/ 3.4 ltr.
Overheat Warning
HOT on Instrument
Cluster
Lubrication
Pressurized Wet Sump
Oil Requirements /
Capacity
Polaris 2W-50 2 qt. / 1.9
liters
Exhaust System Single Pipe / Silencer
Fuel System
Fuel System Electronic Fuel Injection
Fuel Pump 25L per hour at 39 PSI
Fuel Filter(s)
30 micron in Tank -
(unserviceable)
EFI System
Bosch
Fuel Capacity /
Requirement
4.13 gal US / 15.6 liters
87 Octane (minimum) or
89 Oxygenated
Electrical
Alternator Output (2012) 500 w @ 6000 RPM
Alternator Output (2013 -
2014)
500 w @ 3000 RPM
Lights: Pod Light
50 watts
Grill Light
Two x 37 watts
Brake Light
26.9 watts x 2
Tail Light
8.26 watts x 2
Ignition Timing 13°BTDC @ 1200 RPM
Spark plug / Gap
RC7YC3 / .035 in. / 0.9
mm
Battery / Amp Hr Lead Acid / 30 Amp Hr
Circuit Breakers
Fan 20 amp / Harness 20
amp /
ECU 15 amp / Inst.
Cluster /
Voltage Regulator 6 amp
DRIVETRAIN
Transmission Type
Drumshift - H/L/N/
Rev/Park
Transmission Capacity
17.2 oz. / 510 ml
Front Gearcase Capacity- ADC
9.3 oz. / 275 ml
Mid Gearcase Capacity
13.5 oz. / 400 ml
Rear Gearcase Capacity
5 oz. / 150ml
Gear Ratio: Low
Rev
High
Front Drive
Rear Drive
7.49:1
6.81:1
3.05:1
3.82:1
3.10:1
Clutch Type
PVT w/ EBS
Steering / Suspension
Front Suspension / Shock
A-arm / MacPherson
Strut
Front Travel 8.2 in. / 21 cm
Rear Suspension / Shock
Progressive Rate
Independent -
Coil - over shock
Rear Travel 6.12 in. / 15.54 cm
Ground Clearance 10.50 in. / 26.67 cm
Shock Preload Adjustment
Front / Rear
Front -Non
Adjustable.
Rear - Ratchet
Style- Std.
Turning Radius
152 in. / 386.08 cm
Toe Out
0 - 1/16 in / .0 - .159
mm
Wheels / Brakes
Front Tire Size 25 x 8 - 12
Rear Tire Size 25 x 11 - 12
Tire Pressure
Front - 7 psi (48.25
Kpa)
Rear - 10 psi (69
Kpa)
Brake - Front and Rear
Dual Hydraulic Disc
Clutching
ALTITUDE
(METERS
(FEET))
SHIFT
WEIGHT
DRIVE CLUTCH
SPRING
0-1800
(0-6000)
21-74
5632117
w/EBS
Red / Blue
7043372
w/EBS
1800-3700
(6000-12000)
21-70
5632127
w/EBS
Red / Blue
7043372
w/EBS
GENERAL INFORMATION
