5
5.25
9924864 - 2012-2014 SPORTSMAN 800 / 6X6
© Copyright 2013 Polaris Sales Inc.
Steering Post Assembly
NOTE: Steering post bearing is shown in exploded
view form. This bearing is attached to the post using
a radial riveting method and is a non-serviceable
item. Steering post replacement is required in the
event of a bearing failure.
1. Hand tighten steering post slotted nut (A).
2. Align the cotter pin hole on the steering post slotted
nut (A).
3. Install the cotter pin (B). Bend both ends of the cotter
pin around the slotted nut (A) in opposite directions.
4. Check the steering, the handle bars must move
freely and easily from full left to full right without
binding.
BODY / STEERING / SUSPENSION
