9
9.13
9924864 - 2012-2014 SPORTSMAN 800 / 6X6
© Copyright 2013 Polaris Sales Inc.
FRONT BRAKE PADS
Pad Removal
1. Elevate and support the of the ATV.
CAUTION
Use care when supporting vehicle so that it does not tip
or fall. Severe injury may occur.
2. Remove the wheel.
3. Loosen pad adjuster screw 2-3 turns.
4. Remove caliper from mounting bracket.
5. Push caliper piston into caliper bore slowly using a
C-clamp or locking pliers with pads installed.
NOTE: Brake fluid will be forced through
compensating port into master cylinder fluid
reservoir when piston is pushed back into
caliper. Remove excess fluid from reservoir as
required.
6. Push mounting bracket inward and slip outer brake
pad past edge. Remove inner pad.
BRAKES
