7
7.19
9924864 - 2012-2014 SPORTSMAN 800 / 6X6
© Copyright 2013 Polaris Sales Inc.
5. Inspect the rollers for nicks, scratches, and flat spots.
Also inspect the roll cage for cracks and ensure the
rollers are able to slide up and down and in and out
freely within the roll cage sliding surfaces.
Setting Ring Gear Backlash NON ADC
NOTE: Ring gear backlash is set at the factory. No
adjustment is required, unless the front cover is
replaced or the back lash pad screw is removed.
1. The backlash screw has locking agent that holds it
into place. Use a heat gun to lightly heat up the
locking agent on the screw.
2. Using a hex wrench, turn the back-lash screw out 3-4
turns. Re-apply Loctite 262™ onto the bottom screw
threads.
3. Turn the screw in until it is lightly seated, then turn
the screw out 1/4 turn.
FINAL DRIVE
