2.38
9924864 - 2012-2014 SPORTSMAN 800 / 6X6
© Copyright 2013 Polaris Sales Inc.
Frame, Nuts, Bolts, Fasteners
Periodically inspect the torque of all fasteners in
accordance with the maintenance schedule. Check that
all cotter pins are in place. Refer to specific fastener
torques listed in each chapter.
Wheel Removal: Front Or Rear
1. Stop the engine, place the transmission in gear and
lock the parking brake.
2. Loosen the wheel nuts slightly.
3. Elevate the side of the vehicle by placing a suitable
stand under the footrest frame.
4. Remove the wheel nuts and remove the wheel.
Wheel Installation
1. With the transmission in park and the parking brake
locked, place the wheel in the correct position on the
wheel hub. Be sure the valve stem is toward the
outside and rotation arrows on the tire point toward
forward rotation.
2. Attach the wheel nuts and finger tighten them.
3. Lower the vehicle to the ground.
4. Securely tighten the wheel nuts to the proper torque
listed in the table
CAUTION
Improperly installed wheels could affect vehicle
handling and tire wear. On vehicles with tapered rear
wheel nuts, make sure tapered end of nut goes into
taper on wheel. Torque to proper specification.
ITEM
SPECIFICATION
Steel - Front and Rear
Wheel Nuts
27 ft-lbs (37 Nm)
Aluminum - Front and
Rear Wheel Nuts
30 ft-lbs + 1/4 Turn
(41 Nm + 1/4 Turn)
Front Hub Retaining Nut
60 ft-lbs (81 Nm)
Rear Hub Retaining Nut
80 ft-lbs (108 Nm)
MAINTENANCE
