9
9.21
9924864 - 2012-2014 SPORTSMAN 800 / 6X6
© Copyright 2013 Polaris Sales Inc.
REAR BRAKE PAD
Rear Pad Removal
1. Support the machine. Remove the rear tire.
2. Remove the slide pin clips from the slide bolt.
3. Loosen the slide pins with a hex wrench.
4. Remove caliper mounting bolts and lift caliper off of
disc.
NOTE: When removing caliper, be careful not to
damage brake line. Support caliper so as not to
kink or bend brake line.
5. Push caliper pistons into caliper bore slowly with
pads installed.
6. Remove the caliper slide pins and remove the brake
pads from the caliper.
7. Clean the caliper with brake cleaner or alcohol.
BRAKES
