8.2
9924864 - 2012-2014 SPORTSMAN 800 / 6X6
© Copyright 2013 Polaris Sales Inc.
GENERAL INFORMATION
Torque Specifications (4X4)
COMPONENT FT-LBS
(IN-LBS)
NM
Transmission Case Bolts 25-30 36-43
Bell Crank Nut 12-18 17-26
Transmission Fill/Drain Plug 20-25 29-36
Trans. Mounting Bolts 37-40 50-57
Gear Sector Cover 8-12 11-17
Oil Deflector Screws (20-30) 2-3.6
Snorkel Torx Screw 8-12 11-17
Bearing Cover 8-12 11-17
Carrier Cover
23-27 33-39
Shift Fort Retainer Screws
8-12 11-17
Park Plate
8-12 11-17
Special Tools
PART NUMBER TOOL DESCRIPTION
2871695 (Part of 2871702 Kit) Backlash Setting Tool
2871698 (Part of 2871702 Kit) Rear Output Seal Driver
2871699 (Part of 2871702 Kit)
Rear Driveshaft Seal Guide
2871282
Bearing Seal Driver (50 mm)
Bosch Automotive Service Solutions: 1-800-345-2233 or http://polaris.service-solutions.com/
Lubrication
Refer to Chapter 2 for transmission lubricant type and
capacity.
TRANSMISSION
