Reflex Fillcontrol Plus Compact Original Operating Manual

Innehållsförteckning
118 — Svenska Fillcontrol Plus Compact — 03.05.2022 - Rev. D
inhalt_no
Innehållsförteckning
schwedisch
1 Anvisningar till driftsinstruktionerna .................................. 119
2 Ansvar och garanti ................................................................ 119
3 Säkerhet ................................................................................ 119
3.1 Symbolförklaring .................................................................................119
3.1.1 Anvisningar i driftsinstruktionerna ...................................119
3.2 Krav på personalen ..............................................................................119
3.3 Personlig skyddsutrustning ................................................................119
3.4 Avsedd användning .............................................................................119
3.5 Otillåtna driftsförhållanden ................................................................119
3.6 Restrisker ..............................................................................................119
4 Apparatbeskrivning .............................................................. 119
4.1 Beskrivning ...........................................................................................119
4.2 Översiktsframställning ........................................................................120
4.3 Identifikation ........................................................................................120
4.3.1 Typskylt ................................................................................120
4.4 Leveransomfång ..................................................................................120
4.5 Extrautrustning som tillval ..................................................................120
5 Tekniska data ........................................................................ 120
6 Montering ............................................................................. 120
6.1 Monteringsförutsättningar .................................................................121
6.1.1 Kontroll av leveransens skick .............................................121
6.2 Förberedelser .......................................................................................121
6.3 Genomförande .....................................................................................121
6.4 Kopplingsschema ................................................................................ 121
6.5 Elanslutning ......................................................................................... 121
6.5.1 Plintschema ......................................................................... 122
7 Första idrifttagning ............................................................... 122
7.1 Förutsättningar för idrifttagning ....................................................... 122
7.2 Bestämma lägsta drifttryck P
0
för styrningen ................................... 122
7.2.1 Mata in lägsta drifttryck i styrningen ................................ 122
7.2.2 Ställa in tryckregulatorn ..................................................... 123
7.2.3 Fylla anläggningen med vatten ........................................ 123
7.2.4 Rengöra smutsfälla ............................................................. 123
8 Drift ........................................................................................ 123
8.1 Driftsätt ................................................................................................. 123
8.1.1 Automatdrift ....................................................................... 123
8.1.2 Nödstängningsfunktion ..................................................... 123
8.2 Fabriksinställningar i servicemenyn .................................................. 123
8.3 Felmeddelanden .................................................................................. 124
9 Underhåll ............................................................................... 124
10 Demontering ......................................................................... 125
11 Bilaga ..................................................................................... 125
11.1 Reflex kundtjänst ................................................................................. 125
11.2 Överensstämmelse/standarder .......................................................... 125
11.3 Garanti .................................................................................................. 125
ivz_se
Svens k a
03.05.2022 - Rev. D
