RL78/G13 CHAPTER 2 PIN FUNCTIONS
R01UH0146EJ0100 Rev.1.00 81
Sep 22, 2011
(h) SCL10
This is a serial clock output pin of serial interface IIC10.
(i) TI00, TI05, TI06
There are the pins for inputting an external count clock/capture trigger to 16-bit timers 00, 05, and 06.
(j) TO00, TO05, TO06
These are the timer output pins of 16-bit timers 00, 05, and 06.
2.2.2 P10 to P17 (port 1)
P10 to P17 function as an I/O port. These pins also function as serial interface data I/O, clock I/O, programming UART
I/O, timer I/O, clock/buzzer output, and external interrupt request input.
Use of an on-chip pull-up resistor can be specified by pull-up resistor option register 1 (PU1).
Input to the P10, P11 and P13 to P17 pins can be specified through a normal input buffer or a TTL input buffer in 1-bit
units, using port input mode register 1 (PIM1).
Output from the P10 to P15 and P17 pins can be specified as normal CMOS output or N-ch open-drain output (V
DD
tolerance) in 1-bit units, using port output mode register 1 (POM1).
The following operation modes can be specified in 1-bit units.
(1) Port mode
P10 to P17 function as an I/O port. P10 to P17 can be set to input or output port in 1-bit units using port mode
register 1 (PM1).
(2) Control mode
P10 to P17 function as serial interface data I/O, clock I/O, programming UART I/O, timer I/O, clock/buzzer output, and
external interrupt request input.
(a) INTP5
This is an external interrupt request input pin for which the valid edge (rising edge, falling edge, or both rising and
falling edges) can be specified.
(b) TxD0, TxD2
These are the serial data output pins of serial interface UART0 and UART2.
(c) RxD0, RxD2
These are the serial data input pins of serial interface UART0 and UART2.
(d) SCK00, SCK20
These are the serial clock I/O pins of serial interface CSI00 and CSI20.
(e) SI00, SI11, SI20
These are the serial data input pins of serial interface CSI00, CSI11, and CSI20.
(f) SO00, SO11, SO20
These are the serial data output pins of serial interface CSI00, CSI11, and CSI20.
(g) TI01, TI02
These are the pins for inputting an external count clock/capture trigger to 16-bit timers 01 and 02.
