RL78/G13 CHAPTER 25 FLASH MEMORY

R01UH0146EJ0100 Rev.1.00 937

Sep 22, 2011

25.4 Data Flash

25.4.1 Data flash overview

In addition to 16 to 512 KB of code flash memory, the RL78/G13 with data flash includes 4/8 KB of data flash memory

for storing data.

00000H

EFFFFH

F0000H

F07FFH

F0800H

FFEDFH

FFEE0H

FFEFFH

FFF00H

FFFFFH

Special function register (SFR)

256 bytes

RAM

2 to 32 KB

General-purpose register

32 bytes

Code flash memory

16 to 512 KB

Special function register (2nd SFR)

2 KB

Reserved

Mirror

Data flash memory

4/8 KB

F0FFFH

F1000H
